BMEH584040K – Modicon M580 – Hot Standby Kit – consisting of 2 × BMEH584040 + 2 × 490NAC0100

BMEH584040K – Modicon M580 – Hot Standby Kit – consisting of 2 × BMEH584040 + 2 × 490NAC0100

This product is part of the **Modicon M580** range, a family of **Programmable Automation Controllers (PACs)** and **Safety Programmable Logic Controllers (PLCs)** with integrated Ethernet.

This **Hot Standby (HSBY) backup kit** is an accessory kit for Programmable Automation Controllers (PACs) and Safety Programmable Logic Controllers (PLCs). It consists of **2 BMEH584040 processor modules** and **2 490NAC0100 SFP connectors**.

The product has an **IP20 protection rating** and weighs **1.698 kg**.

It is suitable for **medium- to large-scale process applications**.

This product is certified **CE, CSA, RCM, UL, Merchant Navy, and EAC**.

It complies with **EN 61131-2, EN 61000-6-4, EN 61000-6-2, and EN 61010-2-201** standards.

It helps **increase operational profitability through improved access to data**.

SKU: 1207 Category:
Technical data sheet
User manual

TECHNICAL SPECIFICATIONS

Description Value
Product range Modicon M580
Marking CE
Vibration resistance 3 gn
Mechanical shock resistance 30 gn
Operating temperature -25 to 60 °C
Storage temperature -40 to 85 °C
Operating altitude 0 to 2000 m
2000 to 4000 m with derating factor
Relative humidity 5 to 95 % at 55 °C without condensation
Degree of protection IP20
European directives 2014/35/EU (Low Voltage Directive)
2014/30/EU (Electromagnetic Compatibility)
Product certifications CE
UL
CSA
RCM
EAC
Marine
Standards IEC 61131-2
IEC 61010-2-201
UL 61010-2-201
CSA C22.2 No 61010-2-201
IACS E10
EN/IEC 61000-6-5 (interface type 1 and type 2)
EN/IEC 61850-3 (location G)
Hazardous area Class I Division 2
Net weight 1.698 kg
Packaging 1 PCE – 1 unit – 15.0 × 30.0 × 40.0 cm – 2.202 kg
Packaging 2 P06 – 8 units – 45.0 × 60.0 × 80.0 cm – 27.616 kg
Contractual warranty 18 months
